Leaf

TOUCH SCREEN, AUDIO/VIDEO DEVICE

Users can experience your content like never before on the Leaf’s high quality screen and through its dynamic audio.

Easily navigate the secure audio, video and image content with the intuitive, icon-driven touch screen. This durable Leaf is charged through a USB-C cable and can be paired with solar panels and backup battery, allowing you to extend your reach.

General:

  • Video playback
  • Audio playback
  • Document viewer (initially only PDF)
  • Image viewer
  • Image slideshow
  • 10.1” (1280 x 800 pixels) IPS display with capacitive touch functionality
  • Power/display on/off combo button
  • Two built-in, front-facing speakers
  • Reset button



Connectivity:

  • 3.5mm stereo earphone jack
  • USB-C (charge and connectivity)
  • USB-A (OTG) port
  • MicroSD port1
  • Supports video output over mini-HDMI connector (adaptor cable included)



Graphical Indications:

  • Charge
  • Battery capacity
  • Volume level + mute
  • Brightness level
  • Connected/selected storage(s)
  • Display/audio connection and output
  • Brightness and volume controls
  • Display output controls



Media Browsers:

  • Audio (AAC, M4A, MP3, OGG, WAV)
  • Video (AVI, FLV, M4V, MKV, MOV, MPG, MP4)
  • Images (BMP, GIF, JPG, PNG, MVI)
  • Documents (PDF)



Navigation Control:

  • Previous/next page (image/video/audio)
  • First/last page (documents only)
  • Skip 15 seconds forward/backwards (audio/video)
  • Play/pause (audio/video/slideshow)
  • Rotate (image/document)
  • Zoom in/out (image/document)
  • Fit to display (image/document)
  • Shuffle (audio/video/slideshow)
  • Repeat one/all (audio/video)

Bookmarks:

  • Display orientation (image/document)
  • Path to last accessed file, per media browser
  • Last viewed page (document)
  • Last playback position (audio/video)
  • Headings multilevel list (document)



Storage:

  • Internal available in 32GB, 64GB or 128GB (per MOQ / stock availability)
  • External – any standard microSD/OTG up to 128GB1



Battery:

  • 10,000mAh built-in Li-Ion battery
  • Charge indication LED
  • Average play time: 6h 7m @ max volume and brightness2
  • Typical charge time: 6h 30m3



Security:

  • Internal storage:
    – Access via USB – requires SLS-v2 cable from SGS
    – Encryption – optional. Supports both encrypted and non-encrypted content
  • External storages: (microSD / OTG)
    – Access via USB – any USB cable (microSD only)
    – Encryption – required!



Size:

  • 260 x 190 x 28mm / 800g
  • 10.2 x 7.5 x 1.1” / 28.22oz



Multi filesystem support: (NTFS, FAT32, exFAT)

System information screen

Automatic and interactive firmware update

Built-in test screens (display, audio, touch)

Battery

  • Internal battery: 10,000mAh Lithium Ion
  • Average play time: 6h 7m @ max volume and brightness2
  • Typical charge time: 6h 30m3
  • Charge indicator: On-screen and LED

Charging

With proper care, the player’s Lithium-Ion battery should perform well for several years. When shipped, the battery is only partially charged. You can easily charge the player using one of the methods below:

External Power Supply

For fastest charge use a regulated 5V – 2000mA (or higher) USB charger4, 5, or an equivalent Power Bank4, 5, connected to the USB-C port on the back of the Envision. A compatible solar panel4, 5 may also be used.

Computer

Connect the tablet from any standard computer USB port to the USB-C port on the back of the Envision until the charging icon stops blinking4, 6.

1MicroSD card not included
2Your playtime may vary
3Actual charge time will vary according to the current battery capacity and charging source
4Power bank and solar panel not included
5A solar panel is the least stable/reliable among the options above
6Most computer standard USB ports provide a limited power output of only around 500mA. USB-C ports may supply higher power outputs.
